Kreissäge RS. All In.
-
No maybe. No hesitation. No second guessing. In bike racing there is no time for all this.
It’s all in or nothing. Or as the living legend Wayne Gretzky once said: “You miss 100% of the shots you don’t take.”
The Kreissäge RS is here to get the most out of every shot you take. Stiffer, lighter and faster than ever. Made from Scandium aluminium. Fully integrated cabling. Proven race winning geometry. Simply the best racing bike we’ve ever made. Made to go fast, brake late, hit the apex, accelerate out of turns and sprint for whatever you are sprinting for. Agile, direct, responsive, safe. Control is fast.
With the shapes of bikes getting weirder and generic at the same time we stick to our classy design but give it the latest update of fully integrated cabling and optimized Scandium tubing.- • Full internal cable routing for electronic and mechanical groupsets
- • Custom T47 bb shell with machined inside for optimized weight and space for internal cable routing
- • Tire clearance to fit up to 30mm tires
- • High end Scandium Aluminium frame with full carbon fork
- • Race proven geometry for superior pedaling efficiency and handling
- • Engineered in Berlin, Made in Italy
Shop Kreissäge RS online or visit us in Berlin.
FACT SHEETS -
*Image shows size 54 with Dura Ace Di2 R9200 setup
Regular price
€0.00 EUR
€4,999.00 EUR
price without VAT:
€4,200.84 EUR
excl. shipping / incl. VAT

Specs
Stem | Deda Vinci POB | |
Handlebar | Deda Superzero Carbon | |
Handlebar Tape / Grips | Fizik | |
Shift / Brake Levers | Shimano Dura Ace 9200 | |
Brake Front | Shimano Dura Ace 9200, 160mm Rotor | |
Brake Rear | Shimano Dura Ace 9200, 140mm Rotor | |
Derailleur Front | Shimano Dura Ace 9200 | |
Derailleur Rear | Shimano Dura Ace 9200 | |
Cassette | Shimano Dura Ace 9200 10-28 | |
Chain | Shimano Dura Ace | |
Crankset | Shimano Dura Ace 9200, 5236 | |
Saddle | Fizik Vento Argo R1 | |
Seatpost | Zipp SL Speed carbon |
Frame | Standert Kreissäge RS | |
Fork | Standert full carbon integrated tapered 1 1/8"-1 1/2" flat mount | |
Sizes | 48 Project Compact™, 50 Project Compact™, 52 Project Compact™, 54, 56, 58, 60 | |
Weight | Complete (Size 54) 8,0 kg | |
Max. Tire Clearance | 700x30C | |
Recom. max. rider weight | 95 kg | |
Headset | Standert Integrated | |
Bottom Bracket | First T47 | |
Wheelset | Scope R4 Disc | |
Tires | Vittoria Corsa |
Geometry
48 PC™ | 50 PC™ | 52 PC™ | 54 | 56 | 58 | 60 | ||
---|---|---|---|---|---|---|---|---|
Seat Tube Length | 480 | 490 | 500 | 530 | 550 | 571 | 586 | |
Top Tube Length | 495 | 512 | 525 | 544 | 555 | 570 | 586 | |
Head Tube Length | 110 | 115 | 120 | 130 | 145 | 166 | 181 | |
Seat Tube Angle | 76.5 | 76 | 75.5 | 74 | 73.5 | 73.5 | 73.5 | |
Head Tube Angle | 71.25 | 72.5 | 73 | 73 | 73.5 | 73.5 | 73.5 | |
Stack | 521 | 530 | 537 | 544 | 560 | 580 | 595 | |
Reach | 370 | 380 | 386 | 388 | 390 | 398 | 410 | |
Chainstay Length | 405 | 405 | 405 | 410 | 410 | 410 | 410 | |
Wheelbase | 969 | 970 | 974 | 984 | 986 | 1000 | 1016 | |
Standover Height | 741 | 745 | 758 | 778 | 794 | 816 | 830 | |
Crankset | 165 | 170 | 170 | 170 | 172.5 | 172.5 | 172.5 | |
Stem | 100 | 110 | 110 | 120 | 120 | 130 | 130 | |
Handlebar Width (C-C) | 38 | 38 | 38 | 40 | 40 | 42 | 42 | |
Seatpost | 0 | 0 | 0 | 0 | 20 | 20 | 20 |
Sizing
Body Height (cm) | Inseam (cm) | Frame Size | ||||||
---|---|---|---|---|---|---|---|---|
150 | - | 163 | 76 | - | 82 | 48 PC™ | ||
158 | - | 170 | 77 | - | 83 | 50 PC™ | ||
166 | - | 177 | 78 | - | 84 | 52 PC™ | ||
170 | - | 180 | 80 | - | 86 | 54 | ||
175 | - | 185 | 82 | - | 88 | 56 | ||
182 | - | 192 | 84 | - | 90 | 58 | ||
188 | - | 198 | 85 | - | 91 | 60 | ||
regular fit | race fit | regular fit | race fit |
