We really like the approach of taking it easy, shifting down a gear, deep breaths, observing and feeling nature around us.

But to be honest when we are on our race bikes we just want that nature thing flying by left and right. Deep breaths should come from our hearts pumping at 190bpm and shifting down a gear should only be in preparation to drop the hammer.
The Kreissäge RS is an aluminium road bike frame made to go fast, brake late, hit the apex, accelerate out of turns and sprint for whatever you are sprinting for. Agile, direct, responsive, safe. Control is fast.

Fast is still F.U.N.

What’s new on the RS?

• Internal Di2 cable routing for tidy looks and reduced wear and tear. External brake cables for ease of service and external cable stops for mechanical shifting optional.

• Custom T47 bb shell with machined inside for optimized weight and space for internal cable routing.

• More tire clearance to fit up to 28mm tires.

What remains the same?

• High end Scandium Aluminium frame with full carbon fork

• The same race proven geometry for superior pedaling efficiency and handling

• Engineered in Berlin, Made in Italy

Shop Kreissäge RS RIM online or visit us in Berlin.

*Image shows size 54

$SECTION_IMAGE

$SECTION_DISCOVER
60;8; kreissaege-rs-rim-frameset-blue-moon-lucky-cat
16;64; kreissaege-rs-rim-frameset-blue-moon-dropout
50;39; kreissaege-rs-rim-frameset-blue-moon-side-profile
43;39; kreissaege-rs-rim-frameset-blue-moon-made-in-italy
28;35;kreissaege-rs-rim-frameset-blue-moon-back-crop
75;20; kreissaege-rs-rim-frameset-blue-moon-front-badge
75;32; kreissaege-rs-rim-frameset-blue-moon-cabling-detail
83;55; kreissaege-rs-rim-frameset-blue-moon-front-view
57;30;kreissaege-rs-rim-frameset-blue-moon-frame-crop
20;50; kreissaege-rs-rim-frameset-blue-moon-back-diagonal
42;28; kreissaege-rs-rim-frameset-blue-moon-seat-stem
49;80; kreissaege-rs-rim-frameset-blue-moon-bb
45;68; kreissaege-rs-rim-frameset-blue-moon-decals

$SECTION_QUOTE

$SECTION_SPECS

Frameset; ;Included in the frameset:
Frame;frame;Standert Kreissäge RS RIM
Fork;fork;Standert tapered full carbon direct mount
Headset;headset;Standert ZS/EC
Bottom Bracket;bottom-bracket;First T47
Seatpost Clamp;seatpost-clamp;31.8mm
; ;

Dimensions; ;Additional dimensions are:
Seatpost Diameter;seatpost;27.2mm
Front Derailleur Clamp Diameter;front-derailleur-clamp-diameter;31.8mm
Max. Tire Clearance;max.-tire-clearance;700x28c
; ;

Colors;colors;;Team Edition, Blue Moon, Royal Navy, Fluo Forest
Sizes;sizes;48 Project Compact™, 50 Project Compact™, 52 Project Compact™, 54, 56, 58, 60
Weight;weight-kg;Frame (size 56) 1360g, Fork 350g
Recom. max. rider weight;recom.-max.-rider-weight;90 kg

$SECTION_GEOMETRY 48 PC™;50 PC™;52 PC™;54;56;58;60
a;Seat Tube Length;480;490;500;530;550;571;586
b;Top Tube Length;495;512;525;544;555;570;586
c;Head Tube Length;110;115;120;130;145;166;181
d;Seat Tube Angle;76.5;76;75.5;74;73.5;73.5;73.5
e;Head Tube Angle;71.25;72.5;73;73;73.5;73.5;73.5
f;Stack;521;530;537;544;560;580;595
g;Reach;370;380;386;388;390;398;410
h;Chainstay Length;405;405;405;410;410;410;410
i;Wheelbase;969;970;974;984;986;1000;1016
;Standover Height;741;745;758;778;794;816;830

$SECTION_SIZING Body Height;cm;Inseam;cm;Frame Size
150;163;76;82;48 PC™
158;170;77;83;50 PC™
166;177;78;84;52 PC™
170;180;80;86;54
175;185;82;88;56
182;192;84;90;58
188;198;85;91;60
regular fit;race fit;regular fit;race fit
