Triebwerk Blue | Steel Road Bike Frame Made for Performance Triebwerk | Frameset | Blue Orchid - Standert Bicycles Triebwerk | Frameset | Blue Orchid - Standert Bicycles
Home » Road Performance » Triebwerk » Triebwerk | Frameset | Blue Orchid

Triebwerk | Frameset | Blue Orchid

Save €250

1,599.00 EUR

1,849.00 EUR

price without VAT: 1,343.70 EUR

or from
€23.24 EUR/month
Color
Size
48 PC™
50 PC™
52 PC™
54
56
58
60
about Project Compact™

Geometry

Size guide

1: Select size
1: Size selected
2: Configure
2: Configured
3: Add to cart
3: Add to cart
A steel made road bike frame crafted for performance.
Custom-engineered Standert integrated headset designed to fit our new head tube profile.
Columbus monocoque carbon fork; 45mm rake. 160mm max rotor clearance. 32mm max tire clearance (actual width).
Hand-built in Taiwan with a select mix of Columbus Spirit & Life steel tubes.
Fully integrated cable routing.

Shipping

Reviews

Configure your Triebwerk | Frameset | Blue Orchid

Frame
Standert Triebwerk

Fork
Columbus Futura Disc 1 1/8" - 1/4"

Headset
Standert Integrated

Bottom Bracket
First T47

Seatpost Clamp
31.8mm

Through Axles
Front 12x100, rear 12x142

Front Derailleur Clamp Diameter
31.8mm

Max. Tire Clearance
700x32c

Ready for
1x, 2x, Di2, eTap, EPS

Weight
Frame (size 56) 1830g, Fork 440g

Add-Ons

Price for current setup

Triebwerk | Frameset | Blue Orchid

Size
not set
Group
not set

1,599.00 EUR

Total Discount: €249.90

price without VAT: 1,129.00 EUR

Shipping in 1-3 weeks.
Triebwerk Blue Orchid Steel Road Bike Frame Triebwerk Blue Orchid Steel Road Bike Frameset Triebwerk Blue Orchid Road Bike Made from Steel Triebwerk Blue Orchid Steel Road Bike Frame Bottom Bracket Triebwerk Blue Orchid Steel Road Bike Frame Down Tube Logo Triebwerk Blue Orchid Steel Road Bike Frame Dropout Triebwerk Blue Orchid Steel Road Bike Frame Headset Triebwerk Blue Orchid Steel Road Bike Frame Fork Triebwerk Blue Orchid Steel Road Bike Frame Headtube Logo Triebwerk Blue Orchid Steel Road Bike Frame Lucky Cat Triebwerk Blue Orchid Steel Road Bike Frame Seat Clamp Triebwerk Blue Orchid Steel Road Bike Frameset

Geometry

48 PC™
50 PC™
52 PC™
54
56
58
60
A
Seat Tube Length
480
490
515
540
555
570
585
B
Top Tube Length
502
514
530
544
560
570
582
C
Head Tube Length
97
105
113
128
142
158
174
D
Seat Tube Angle
76.5
76
75
74.5
74
74
74
E
Head Tube Angle
71.25
72
72.5
73
73.5
73.5
73.5
F
Stack (No Headset)
509
519
529
545
560
575
590
G
Reach
380
385
389
393
401
406
414
H
Chainstay Length
405
405
408
410
410
412
412
I
Wheelbase
976
977
983
989
997
1009
1021
J
Standover Height
737
747
763
782
797
811
826
Headset Stack
26
26
26
26
26
26
26

Size Guide

A
Body Height (cm)
B
Inseam (cm)
Frame Size
150
-
163
76
-
82
48 PC™
158
-
170
77
-
83
50 PC™
166
-
177
78
-
84
52 PC™
170
-
180
80
-
86
54
175
-
185
82
-
88
56
182
-
192
84
-
90
58
188
-
198
85
-
91
60
regular fit
race fit
regular fit
race fit
Shipping
Destination
Costs
€30
€40
€160
€230
€120
€320
Time
1-3 Weeks
1-3 Weeks
1-3 Weeks
1-3 Weeks
1-3 Weeks
1-3 Weeks
All in-stock and available products are subject to processing & shipping times stated here. Every frame is hand-prepared in our Berlin warehouse. All orders undergo careful preparation, including: facing & reaming bearing surfaces, chasing threads, installing small parts, and thorough quality control. We promise it’s worth the wait.
Find out more about Shipping & Deliveries.
All in-stock and available products are subject to processing & shipping times stated here. Every frame is hand-prepared in our Berlin warehouse. All orders undergo careful preparation, including: facing & reaming bearing surfaces, chasing threads, installing small parts, and thorough quality control. We promise it’s worth the wait.
Find out more about Shipping & Deliveries.
All in-stock and available products are subject to processing & shipping times stated here. Every frame is hand-prepared in our Berlin warehouse. All orders undergo careful preparation, including: facing & reaming bearing surfaces, chasing threads, installing small parts, and thorough quality control. We promise it’s worth the wait.
Find out more about Shipping & Deliveries.
All in-stock and available products are subject to processing & shipping times stated here. Every frame is hand-prepared in our Berlin warehouse. All orders undergo careful preparation, including: facing & reaming bearing surfaces, chasing threads, installing small parts, and thorough quality control. We promise it’s worth the wait.
Find out more about Shipping & Deliveries.
All in-stock and available products are subject to processing & shipping times stated here. Every frame is hand-prepared in our Berlin warehouse. All orders undergo careful preparation, including: facing & reaming bearing surfaces, chasing threads, installing small parts, and thorough quality control. We promise it’s worth the wait.
Find out more about Shipping & Deliveries.
All in-stock and available products are subject to processing & shipping times stated here. Every frame is hand-prepared in our Berlin warehouse. All orders undergo careful preparation, including: facing & reaming bearing surfaces, chasing threads, installing small parts, and thorough quality control. We promise it’s worth the wait.
Find out more about Shipping & Deliveries.
