Configure your Triebwerk | Frameset | Silver Lily
Frame
Standert Triebwerk
Fork
Columbus Futura Disc 1 1/8" - 1/4"
Headset
Standert Integrated
Bottom Bracket
First T47
Seatpost Clamp
31.8mm
Through Axles
Front 12x100, rear 12x142
Front Derailleur Clamp Diameter
31.8mm
Max. Tire Clearance
700x32c
Ready for
1x, 2x, Di2, eTap, EPS
Weight
Frame (size 56) 1830g, Fork 440g
Add-Ons
Price for current setup
Triebwerk | Frameset | Silver Lily
Size
not set
In Stock. Framesets ship in 4 weeks. All frames require some work and are prepared to order by our in-hous team of mechanics.
Geometry
48 PC™
50 PC™
52 PC™
54
56
58
60
A
Seat Tube Length
480
490
515
540
555
570
585
B
Top Tube Length
502
514
530
544
560
570
582
C
Head Tube Length
97
105
113
128
142
158
174
D
Seat Tube Angle
76.5
76
75
74.5
74
74
74
E
Head Tube Angle
71.25
72
72.5
73
73.5
73.5
73.5
F
Stack (No Headset)
509
519
529
545
560
575
590
G
Reach
380
385
389
393
401
406
414
H
Chainstay Length
405
405
408
410
410
412
412
I
Wheelbase
976
977
983
989
997
1009
1021
J
Standover Height
737
747
763
782
797
811
826
Headset Stack
26
26
26
26
26
26
26
Size Guide
A
Body Height (cm)
B
Inseam (cm)
Frame Size
150
-
163
76
-
82
48 PC™
158
-
170
77
-
83
50 PC™
166
-
177
78
-
84
52 PC™
170
-
180
80
-
86
54
175
-
185
82
-
88
56
182
-
192
84
-
90
58
188
-
198
85
-
91
60
regular fit
race fit
regular fit
race fit
Shipping
Destination
Costs
€30
Time
4 Weeks
All in-stock and available products are subject to processing & shipping times stated here. Every frame is hand-prepared in our Berlin warehouse. All orders undergo careful preparation, including: facing & reaming bearing surfaces, chasing threads, installing small parts, and thorough quality control. We promise it’s worth the wait.
Find out more about Shipping & Deliveries.
